Use steel plate welding machine seat, Machining after annealing. Integrated design of machinery, measurement system and strong power control switch, Occupying a small area(Special requirements can be separated and installed). Suitable for single -sided balance measurement，Such as car accessories, etc., high -precision workpieces with special requirements.
Tel:+86-13375386268
Email: beacon@beacon-machine.com
1.Product structure:
(1)Single -sided vertical braking function
(2)Using the most universal figures and simulated integrated electrical appliances
(3)The amount, speed, and phase are displayed in numbers
2.Application range:for fans.extraction fans,brakes.juice blenders range hoods ,blowers
3.Product advantages:
(1) with memory function
(2) Easy to operate
(3) easy installation
(4) instant results printing
Type:YF-5
Mass of work（KG）:5
Max.dia of works（MM）:500
Balancing speed（R/MIN）:300-3500
Motor power（KW）:0.37
Min.achieveable unbalance:≤5
Unbalance reduction ratio（%）:≥90%
Machine tool length（MM）:1100
Net machine net weight（KG）:120
Size LxWxH（MM）:1100x800x850
