1. Drive mode: motor drive, power 7.5KW.
2. Speed regulation mode: frequency conversion speed regulation equipment, arbitrary forward and reverse rotation.
3. Loading method: Fully automatic ESC proportional valve loading 30MPa.
4. Display mode: The computer displays the speed, flow, mechanical efficiency, volumetric efficiency, noise, pressure, and the pressure is dually displayed by the computer and the shock-resistant pressure gauge. Self-priming fuel supply mode.
5. Test components: mainly test hydraulic pumps.
6. Motor steering: both left and right rotation can be tested. The lateral test of the oil pump is added to test the pressure and flow rate under the working conditions of 800, 1500, and 2800r/min, respectively, and display them on the computer. The speed can be freely modified.
7. Motor pump connection: rubber sleeve connection. Install a torque sensor.
8. Collection of leaked oil: one oil return tank.
9 Inlet and return oil filtration: 80μm oil inlet filter element, 30μm oil return filter element.
